YA10系列
◆ 全球通用輸入范圍85-256Vac
◆ 單路、雙路及三路輸出
◆ 2500Vac隔離耐壓
| 型號 | 功率 (W) | 輸入電壓(VAC) | 輸出電壓(VDC) | 輸出電流(VDC) | 輸出類型 | 隔離電壓(VAC) | 封裝尺寸 (mm) | 應(yīng)用行業(yè) | 應(yīng)用資料 |
|---|---|---|---|---|---|---|---|---|---|
| YAT10-05H15-WI | 10 | 85-265Vac/120-375Vdc | 5/±15 | 1.1/±0.2 | 三路 | 2500Vac | 62.0*45.0*22.5 | 通用 |  |
| YAT10-0515-WI | 10 | 85-265Vac/120-375Vdc | 5/±15 | 1.4/±0.1 | 三路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAT10-05H12-WI | 10 | 85-265Vac/120-375Vdc | 5/±12 | 1.1/±0.2 | 三路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAT10-0512-WI | 10 | 85-265Vac/120-375Vdc | 5/±12 | 1.5/±0.1 | 三路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-05H24-WI | 10 | 85-265Vac/120-375Vdc | 5/24 | 1.1/0.2 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-0524-WI | 10 | 85-265Vac/120-375Vdc | 5/24 | 1.5/0.1 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-05V15-WI | 10 | 85-265Vac/120-375Vdc | 5/15 | 1.1/0.3 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-05H15-WI | 10 | 85-265Vac/120-375Vdc | 5/15 | 1.4/0.2 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-0515-WI | 10 | 85-265Vac/120-375Vdc | 5/15 | 1.7/0.1 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
| YAD10-05V12-WI | 10 | 85-265Vac/120-375Vdc | 5/12 | 1.1/0.4 | 雙路 | 2500Vac | 62.0*45.0*22.5 | 通用 | |
