YA10-S系列
◆ 全球通用輸入范圍85-256Vac
◆ 單路、雙路及三路輸出
◆ 2500Vac隔離耐壓
| 型號 | 功率 (W) | 輸入電壓(VAC) | 輸出電壓(VDC) | 輸出電流(VDC) | 輸出類型 | 隔離電壓(VAC) | 封裝尺寸 (mm) | 應用行業 | 應用資料 |
|---|---|---|---|---|---|---|---|---|---|
| YAD10-0515-SWI | 10 | 85-265Vac/120-375Vdc | 5/15 | 1.7/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 |  |
| YAD10-05V12-SWI | 10 | 85-265Vac/120-375Vdc | 5/12 | 1.1/0.4 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-05H12-SWI | 10 | 85-265Vac/120-375Vdc | 5/12 | 1.5/0.2 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-0512-SWI | 10 | 85-265Vac/120-375Vdc | 5/12 | 1.8/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-05V05-SWI | 10 | 85-265Vac/120-375Vdc | 5/5 | 1.8/0.2 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-05H05-SWI | 10 | 85-265Vac/120-375Vdc | 5/5 | 1.8/0.2 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-0505-SWI | 10 | 85-265Vac/120-375Vdc | 5/5 | 2/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-24-SW | 10 | 85-265Vac/120-375Vdc | ±24 | ±0.21 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-15-SW | 10 | 85-265Vac/120-375Vdc | ±15 | ±0.33 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD10-12-SW | 10 | 85-265Vac/120-375Vdc | ±12 | ±0.42 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
