YA5系列
◆ 全球通用輸入范圍85-256Vac
◆ 單路、雙路及三路輸出
◆ 2500Vac隔離耐壓
| 型號(hào) | 功率 (W) | 輸入電壓(VAC) | 輸出電壓(VDC) | 輸出電流(VDC) | 輸出類型 | 隔離電壓(VAC) | 封裝尺寸 (mm) | 應(yīng)用行業(yè) | 應(yīng)用資料 |
|---|---|---|---|---|---|---|---|---|---|
| YAT5-0515-WI | 5 | 85-265Vac/120-375Vdc | 5/±15 | 0.6/±0.08 | 三路 | 2500Vac | 55.0*45.0*21.0 | 通用 |  |
| YAT5-0512-WI | 5 | 85-265Vac/120-375Vdc | 5/±12 | 0.6/±0.1 | 三路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-0524-WI | 5 | 85-265Vac/120-375Vdc | 5/24 | 0.6/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-0515-WI | 5 | 85-265Vac/120-375Vdc | 5/15 | 0.7/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-05H12-WI | 5 | 85-265Vac/120-375Vdc | 5/12 | 0.6/0.2 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-0512-WI | 5 | 85-265Vac/120-375Vdc | 5/12 | 0.8/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-05V05-WI | 5 | 85-265Vac/120-375Vdc | 5/5 | 0.7/0.3 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-05H05-WI | 5 | 85-265Vac/120-375Vdc | 5/5 | 0.8/0.2 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-0505-WI | 5 | 85-265Vac/120-375Vdc | 5/5 | 1/0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
| YAD5-24-W | 5 | 85-265Vac/120-375Vdc | ±24 | ±0.1 | 雙路 | 2500Vac | 55.0*45.0*21.0 | 通用 | |
